Dell PS Series User Manual

Installation and Setup Software Configuration
3–8
For example, the following command configures member1 with RAID50:
Using the GUI to Set the RAID Policy
For the latest information on browser support for the Group Manager GUI, see the
PS Series Release Notes.
To use the GUI to set the RAID policy for a member:
1. Log in to the group by entering the group IP address in a Web browser. Then,
in the login dialog box (Figure 3-1), enter the
grpadmin account name and
the password that you specified when creating the group.
Figure 3-1: GUI Login
2. In the Group Summary window (Figure 3-2), expand
Members in the far left
panel and select the member name.
group1> member select member1 raid-policy raid50

Dell PS Series Specifications

General

Category	Storage
Type	SAN (Storage Area Network)
RAID Support	RAID 5, RAID 6, RAID 10
Connectivity	iSCSI
Management	Dell Storage Manager
Data Protection	Snapshots, replication
Operating System Compatibility	Windows, Linux, VMware, Hyper-V
Capacity	Varies by model (e.g., 4TB to 1PB)
Product Type	Enterprise Storage Array
