4–Switch Independent Partitioning
Switch Independent Partitioning Setup and Management Options
148 CU0354602-00 L
5. Save your changes (see Figure 4-14).
Figure 4-14. Saving Configuration Changes
6. Reboot the host server after completing the Switch Independent Partitioning
configuration.
The minimum bandwidth settings in the OptionROM are equivalent
to the relative bandwidth settings in the Dell System Setup.
The MaxBW% field is read only in this utility. To adjust the
maximum bandwidth, use a different utility, such as the Dell
System Setup.
When bandwidth settings exist for both Switch Independent
Partitioning and
DCBX
, DCBX takes precedence over Switch
Independent Partitioning. DCBX sets the bandwidth for iSCSI and
NIC traffic, and then Switch Independent Partitioning sets the
bandwidth for the NIC partitions by dividing the NIC bandwidth
allocated by DCBX. For more information, see “Interoperation of
Bandwidth Settings for DCBX and Switch Independent Partitioning”
on page 121.
