Dell Vostro 3580 User Manual

Next steps
1. Replace the SSD
2. Replace the battery
3. Replace the base cover
4. Replace the optical drive assembly
5. Replace the SD memory card
6. Follow the procedure in after working inside your computer
IO board
Removing the IO board
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the optical drive assembly
4. Remove the base cover
5. Remove the battery
6. Remove the hard drive assembly
Steps
1. Disconnect the VGA cable from the I/O board [1].
2. Open the latch and disconnect the I/O board cable from the system board [2].
46
Removing and installing components

Dell Vostro 3580 Specifications

General

Processor	8th Generation Intel Core i5-8265U Processor (6MB Cache, up to 3.9 GHz)
Display	15.6-inch HD (1366 x 768)
RAM	4GB/8GB/16GB DDR4
Storage	1TB 5400 rpm 2.5" SATA Hard Drive
Graphics	Intel UHD Graphics 620
Operating System	Windows 10 Pro (64-bit)
Battery	42WHr, 3-Cell Battery (integrated)
Ports	2 x USB 3.1, 1 x USB 2.0, HDMI, Ethernet, SD card reader
Wireless	802.11ac Wi-Fi
Optical Drive	Optional DVD-RW
Camera	HD 720p
Audio	Stereo speakers
