Next steps
1. Replace the power button board
2. Replace the display assembly
3. Replace the SSD
4. Replace the WLAN
5. Replace the battery
6. Replace the base cover
7. Replace the optical drive assembly
8. Replace the SD memory card
9. Follow the procedure in after working inside your computer
Display bezel
Removing the display bezel
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the optical drive assembly
4. Remove the base cover
5. Disconnect the battery cable from the connector on the system board
6. Remove the memory
7. Remove the WLAN
8. Remove the SSD
9. Remove the hard drive assembly
10. Remove the system fan
11. Remove the heatsink
12. Remove the display assembly
70
Removing and installing components
