Dell Vostro 3583 - Coin-Cell Battery; Removing the Coin-Cell

Next steps
1. Connect the battery cable to the connector on the system board.
2. Replace the base cover
3. Replace the SD memory card
4. Follow the procedure in after working inside your computer
Coin-cell battery
Removing the coin-cell
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the base cover
4. Disconnect the battery cable from the connector on the system board.
Steps
1. Disconnect the coin-cell battery cable from the I/O board [1].
2. Peel the coin-cell battery from the palm rest and keyboard assembly [2].
