Dell Vostro 3583 - Installing the Power Adapter Port; Display Bezel; Removing the Display Bezel

Installing the power adapter port
Steps
1. Place the power adapter port into the slot on the palmrest and keyboard assembly [1].
2. Replace the single (M2x3) screw that secures the power adapter port to the palmrest and keyboard assembly [2].
3. Route the power adapter cable through the routing channels [3].
4. Connect the power adapter cable to the system board [4].
Next steps
1. Replace the power button board
2. Replace the display assembly
3. Replace the SSD
4. Replace the WLAN
5. Replace the battery
6. Replace the base cover
7. Replace the SD memory card
8. Follow the procedure in after working inside your computer
Display bezel
Removing the display bezel
Prerequisites
1. Follow the procedure in before working inside your computer
2. Remove the SD memory card
3. Remove the base cover
4. Disconnect the battery cable from the connector on the system board
Removing and installing components
65
