Dell Vostro 3583 - Installing the System Board

Installing the system board
Steps
1. Align the screw hole on the system board with the screw hole on the palmrest and keyboard assembly [1].
2. Replace the single (M2x4) screw that secures the system board to the palmrest and keyboard assembly [2].
Removing and installing components
61
