20 Technical Overview
Inside View of Your Computer
1 front bezel 2 primary hard-drive
3 graphics-card bracket (optional) 4 secondary hard-drive
5 system board 6 card retention clamp
7 power supply 8 primary optical-drive
9 secondary optical-drive
7
2
1
9
5
6
4
8
3
book.book Page 20 Wednesday, April 4, 2012 2:00 PM
