Delta AH Series User Manual

Chapter 9 Troubleshooting
9-47
9_
Error Code Description Corrective action
16#350B
The acceleration time for the axis is too
short.
Cause: the accleration time for the axis is set too short.
Action: adjust the accleration or increase the time to
acclerate for the axis.
16#350C
The deceleration time for the axis is too
short.
Cause:
the deceleration time for the axis is set too short.
Action: adjust the deceleration or increase the time to
decelerate for the axis.
16#350D
The E-CAM data exceeds the to-read
range.
Cause:
the to-read data length exceeds the setting range
Action: adjust the to-read data length (1~256)
16#350E
The E-CAM data exceeds the to-be
written range.
Cause: the to-read data length exceeds the setting range
Action: adjust the to-read data length (1~256)
16#350F
The axis is in the “Synchronized“ state.
Cause: the axis is in the “Synchronized“ state when the
MC_SetOverride is started
Action: do not have the axis in the “Synchronized“ state
16#3510
Cam velocity setting error.
Cause: DFB_CamKeyPointWrite is linear, but the
velocity of the two end points is not consistent.
Action: The velocity of the two end points on the straight
line need to be the same.
16#3511
Cam acceleration setting error.
Cause: DFB_CamKeyPointWrite curve is linear, but the
acceleration of the two end points are not 0
Action: The acceleration of the two end points on the
straight line need to be 0
16#3512
Cam data does not exist.
Cause: Cam data does not exist.
Action: check the Cam data is correct and download the
Cam data again
16#3513
The written main axis position is smaller
than the previous point.
Cause: the main axis position on the CAM list is equal or
smaller than the previous point
Action: make sure the written CAM points is correct and
download the CAM data again
16#3514
CAM percentage exceeds setting range
(0~100)
Cause: the percentage setting of DFB_CamSwitch
exceeds setting range (0~100)
Action: reset the percentage setting to be within the
setting range (0~100)
16#3526
Error occurs in the previous movement
of the axis.
Cause: error occurs in the axis
Action: clear error
16#3600 The state of axis is incorrect.
Cause: the axis is not in the ready state to execute the
instruction.
Action: this error will cause the axis state to be in
ErrorStop; users need to execute MC_Reset to have the
axis state back to StandStill. Check the state description
and see if there are any contradictions.
