Delta AH Series User Manual

AH Motion Controller – Operation Manual
9-48
_9
Error Code Description Corrective action
16#3601
The buffer size limit in Buffer mode is
reached.
Cause: the number of buffering instructions (with buffer
mode enabled) reached 20.
Action: 1. The error status will lead the axis to
“ErrorStop”. In this case, execute MC_Reset to set the
axis back to “Standstill”. 2. Make sure the total number of
buffering instructions is less than 20 before executing
current instruction.
16#3602
A multiple instructions which are not
allowed to be executed at the same time
are executed.
Cause: the instruction is executed when another
instruction is in execution at the same time. (Both do not
support simultaneously execution)
Action: use MC_Reset to clear the axis error, and set the
axis state to “StandStill.”
16#3603 Buffermode parameter setting error.
Cause: the set value in Buffermode is not valid.
Action:use MC_Reset to clear the axis error, and specify
the input parameters again.
16#3604
Errors occur on the motion direction of
the function block.
Cause: the moving direction of the axis is not correct.
Action: use MC_Reset to clear the axis error, and
specify the input parameters again.
16#3605
Axis group or single axis motion control
function blocks setting error.
Cause: function blocks for axis group or single axis
motion control is set wrong and cannot achieve the target
position during motion.
Action: use DFB_GroupReset or MC_Reset to clear
the error and reset input parameters
16#3606 Motion target distance is 0.
Cause: the target position is not specified with an
available value.
Action: use MC_Reset to clear the axis error, and
specify the input parameters again.
16#3607 Target velocity exceeds setting range.
Cause: the target velocity is not specified with an
available value.
Action: use MC_Reset to clear the axis error, and
specify the input parameters again.
16#3608 Target velocity exceeds setting range.
Cause: the target velocity is not specified with an
available value.
Action: use MC_Reset to clear the axis error, and
specify the input parameters again.
16#3612
It has reached the positive limit.
Cause: positive limit is reached.
Action: use MC_Reset to clear the axis error, and move
the position potively or negatively to the proprer position.
16#3613
It has reached the negative limit.
Cause: negative limit is reached.
Action: use MC_Reset to clear the axis error, and move
the position potively or negatively to the proprer position.
