AS Series Operation Manual
12-34
_12
12.4.6 Error Codes and LED Indicators for Module AS04SIL IO-Link as
a Communication Module
Error Code Description
MS Status LED indicator
ON Blinking
16#1605
Hardware failure
V
16#1606
24VDC power supply is not sufficient and then recovered
from low-voltage for less than 10 ms.
V
Error Code Description
NS LED indicator
ON
Blinking
16#1800
Error occurs in IO-Link Master
V
16#1801
Error occurs in IO-Link device
V
16#1802
No external power supply
V
12.4.7 Error Codes and LED Indicators for Module AS00SCM as a
Communication Module
Error Code Description
ERROR LED indicator status
ON Blinking
16#1605
Hardware failure
V
16#1606
The setting of the function card is incorrect.
V
16#1802
Incorrect parameters
V
16#1803
Communication timeout
V
16#1804
The setting of the UD Link is incorrect.
V
12.4.8 Error Codes and LED Indicators for Module AS00SCM as a
Remote Module
Error Code Description
ERROR LED indicator status
ON Blinking
Blinking
fast
16#1301
Hardware failure
V
16#1302 The setting of the function card is incorrect. V
16#1303
24 VDC power supply is not sufficient and then is recovered
from a low-voltage less than 10ms situation.
V
16#1502
Incorrect parameters
V
16#1503
Extension module communication timeout
V
