Chapter 8 ParametersASDA-A2R Series
8-52 Revision December, 2014
P1-15 CXFT
Capture Synchronous Axis – Threshold of
Correction
Address: 011EH
011FH
Operational
Interface：
Panel / Software Communication
Related Section:
Default：
0000h
Control
Mode：
ALL
Unit：
-
Range：
0000h ~ 0x1F5F
Data Size：
16bit
Format：
HEX
Settings：
YX: Threshold of correction (%)
Z: Filter intensity
U: Filter is functioning (read-only)
YX: When synchrounous axis captures the signal, the system will
calculate the error. This function is enabled only when the
error is less than the the setting range. Otherwise, the system
will use the new threshold of correction to perform the
operation.
YX 00 01~05F
Function Diabled It will be enabled when error is between 1%
and YX%.
