Chapter 8 ParametersASDA-A2R Series
Revision December, 2014
8-55
Unit：
Pulse unit of compare source
Range：
-10000000 ~ +10000000
Data Size：
32bit
Format：
DEC
Settings：
The real compared data is offset by this value.
CMP_DATA = DATA_ARRAY[*] + P1-23 + P1-24
NOTE
1）P1-23: Non-volatile parameter
2）P1-24: After setting, if P1-19.Z0 = 1, the value will be 0
automatically.
3）CMP_DATA can be monitored via monitoring variable 0x25.
P1-24■
CMOF
COMPARE－Offset Data of CMP (can
reset to 0 automatically)
Address: 0130H
0131H
Operational
Interface：
Panel / Software Communication
Related Section:
Default：
0
Control
Mode：
ALL
Unit：
Pulse unit of compare source
Range：
-32768 ~ +32767
Data Size：
16bit
Format：
DEC
Settings：
The real compared data is offset by this value.
CMP_DATA = DATA_ARRAY[*] + P1-23 + P1-24
NOTE
1）P1-24: volatile parameter.
2）After setting, if P1-19.Z0 = 1, the value will be 0 automatically.
P1-25 VSF1 Low-frequency Vibration Suppression (1)
Address: 0132H
0133H
Operational
Interface：
Panel / Software Communication
Related Section:
6.2.9
Default：
1000
Control
Mode：
PT / PR
Unit：
0.1 Hz
