Delta ASD-A2R-1B43 Series User Manual

Chapter 11 Specifications ASDA-A2R Series
Revision December, 2014
11-25
Motor Frame Size: 100 ~ 130 (Units: mm)
Model
C△1010□ S
C△1020□
S
C△1330□ 4 E△1305□ S E△1310□ S E△1315□ S E△1320□ S
LC 100 100 130 130 130 130 130
LZ 9 9 9 9 9 9 9
LA 115 115 145 145 145 145 145
S
)
(
.
22
0
0130


)
(
.
22
0
0130


)
(24
0
013.0


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


)
(
.
22
0
0130


LB
)
(
.
95
0
0350


)
(
.
95
0
0350


)
(110
0
035.0


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


)
(
.
110
0
0350


LL
(without brake)
153.3 199 187.5 147.5 147.5 167.5 187.5
LL
(with brake)
192.5 226 216.0 183.5 183.5 202 216
LS 37 37 47 47 47 47 47
LR 45 45 55 55 55 55 55
LE 5 5 6 6 6 6 6
LG 12 12 11.5 11.5 11.5 11.5 11.5
LW 32 32 36 36 36 36 36
RH 18 18 20 18 18 18 18
WK 8 8 8 8 8 8 8
W 8 8 8 8 8 8 8
T 7 7 7 7 7 7 7
TP
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
NOTE
1) Dimensions are in millimeters.
2) Dimensions and weights might be revised without prior notice.
3) Box, (□) represents the shaft end/ brake or the number of oil seal.
4) The boxes (ᇞ) in the model names are for encoder resolution types
(ᇞ=1: Incremental encoder, 20-bit; ᇞ=2: Incremental encoder, 17-bit).
