Delta C2000 Plus Series User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-4
Table 7-2
Table 7-3
Model
Applicable
Motor
125% Braking Torque / 10% ED*
1
Max. Braking Torque*
2
HP kW
Braking
Torque
(kg-m)
Brake
Unit
Brake Resistor for
Each Brake Unit*
3
Resistor
Value Spec.
for Each AC
Motor Drive
Total
Braking
Current
(A)
Min.
Resisto
r Value
(Ω)
Max.
Total
Braking
Current
(A)
Peak
Power
(kW)
VFDB*
4
P/N Q’ty Usage
VFD2800C43A-00
VFD2800C43C-21
375 280 189.6 4160*2
BR1K5W012 12
6
parallel,
2 in
series
36000W 2Ω 380 2.0 380 288.8
VFD3150C43A-00
VFD3150C43C-21
425 315 213.3 4160*2 BR1K5W012 12
6
parallel,
2 in
series
36000W 2Ω 380 2.0 380 288.8
VFD3550C43A-00
VFD3550C43C-21
475 355 240.3 4185*2 BR1K5W012 14
7
parallel,
2 in
series
42000W
1.7Ω
450 1.7 450 342.0
VFD4000C43A-00
VFD4000C43C-21
530 400 270.8 4160*3
BR1K5W012 12
6
parallel,
2 in
series
54000W
1.3Ω
540 1.3 540 410.4
VFD4500C43A-00
VFD4500C43C-21
600 450 304.7 4185*3
BR1K5W012 12
6
parallel,
2 in
series
54000W
1.3Ω
600 1.1 675 513.0
VFD5000C43A-00
VFD5000C43C-21
675 500 338.5 4185*3 BR1K5W012 14
7
parallel,
2 in
series
63000W
1.1Ω
675 1.1 675 513.0
VFD5600C43A-00
VFD5600C43C-21
750 560 379.1 4160*4 BR1K5W012 12
6
parallel,
2 in
series
72000W
1.0Ω
760 1.0 760 577.6
575V models
Modle
Applicable
Motor (kW)
125% Braking Torque / 10%ED*
1
Max. Braking Torque*
2
LD ND HD
Braking
Torque
(kg-m)
Brake
Unit
Brake Resistor for
Each Brake Unit*
3
Resistor
Value Spec.
for Each AC
Motor Drive
Total
Braking
Current
(A)
Min.
Resistor
Value
(Ω)
Max.
Total
Braking
Current
(A)
Peak
Power
(kW)
VFDB*
4
P/N Q’ty Usage
VFD015C53A-21
1.5 0.75 0.75 0.5
-
BR080W750 1 - 80W 750Ω 1.2 280.0 4 4.5
VFD022C53A-21
2.2 1.5 1.5 1
-
BR200W360 1 - 200W 360Ω 2.6 186.7 6 6.7
VFD037C53A-21
3.7 2.2 2.2 1.5
-
BR300W400 1 - 300W 400Ω 2.3 160.0 7 7.8
VFD055C53A-21
5.5 3.7 3.7 2.5
-
BR500W100 1 - 500W 100Ω 9.2 93.3 12 13.4
VFD075C53A-21
7.5 5.5 3.7 3.7
-
BR750W140 1 - 750W 140Ω 6.6 80.0 14 15.7
VFD110C53A-21
11 7.5 7.5 5.1
-
BR1K0W075 1 - 1000W 75Ω 12.3 70.0 16 17.9
VFD150C53A-21
15 11 7.5 7.4
-
BR1K1W091 1 - 1100W 91Ω 10.1 62.2 18 20.2
690V models
Model
Applicable
Motor (kW)
125% Braking Torque / 10%ED*
1
Max. Braking Torque*
2
LD ND HD
Braking
Torque
(kg-m)
Brake
Unit
Brake Resistor for
Each Brake Unit*
3
Resistor
Value
Spec. for
Each AC
Motor
Drive
Total
Braking
Current
(A)
Min.
Resistor
Value
(Ω)
Max.
Total
Braking
Current
(A)
Peak
Power
(kW)
VFDB*
4
P/N Q’ty Usage
VFD185C63B-21
18.5 15 11 10.2 - BR1K0W039 2
2 in
series
2000W
78Ω
14.4 58.9 19 21.3
VFD220C63B-21
22 18.5 15 12.5 - BR1K2W033 2
2 in
series
2400W
66Ω
17.0 58.9 19 21.3
