Chapter 3 UnpackingC2000 Plus
3-22
Frame F
Applicable models:
VFD900C23A-00; VFD900C23A-21; VFD1320C43A-00;
VFD1320C43A-21; VFD1600C43A-00; VFD1600C43A-21;
VFD1600C63B-00; VFD1600C63B-21; VFD2000C63B-00;
VFD2000C63B-21
F
Frame G
Applicable models:
VFD1850C43A-00; VFD1850C43A-21; VFD2000C43A-00;
VFD2000C43A-21; VFD2200C43A-00; VFD2200C43A-21;
VFD2500C43A-00; VFD2500C43A-21; VFD2500C63B-00;
VFD2500C63B-21; VFD3150C63B-00; VFD3150C63B-21
Frame H
Applicable models:
VFD2800C43A-00; VFD2800C43C-21; VFD3150C43A-00;
VFD3150C43C-21; VFD3550C43A-00; VFD3550C43C-21;
VFD4000C43A-00; VFD4000C43A-21; VFD4000C63B-00;
VFD4500C43A-00; VFD4500C43C-21; VFD4500C63B-00;
VFD5000C43A-00; VFD5000C43C-21; VFD5600C43A-00;
VFD5600C43C-21; VFD5600C63B-00; VFD6300C63B-00
F
G
H
Figure 3-61
Figure 3-62
Figure 3-63
