Delta C2000 Plus Series User Manual

Chapter 2 InstallationC2000 Plus
2-5
2-2 Airflow and Power Dissipation
Model No.
Airflow Rate for Cooling
Power Dissipation for
AC Motor Drive
Flow Rate (Unit: cfm) Flow Rate (Unit: m
3
/ hr) Power Dissipation (Unit: watt)
External Internal Total External Internal Total
Loss External
(Heat sink)
Internal Total
VFD007C23A-21 - - - - - - 33 27 61
VFD015C23A-21 14 - 14 24 - 24 56 31 88
VFD022C23A-21 14 - 14 24 - 24 79 36 115
VFD037C23A-21 10 - 10 17 - 17 113 46 159
VFD055C23A-21 40 14 54 68 24 92 197 67 264
VFD075C23A-21 66 14 80 112 24 136 249 86 335
VFD110C23A-21 58 14 73 99 24 124 409 121 529
VFD150C23A-21 166 12 178 282 20 302 455 161 616
VFD185C23A-21 166 12 178 282 20 302 549 184 733
VFD220C23A-21 166 12 178 282 20 302 649 216 865
VFD300C23A-00
VFD300C23A-21
179 30 209 304 51 355 913 186 1099
VFD370C23A-00
VFD370C23A-21
179 30 209 304 51 355 1091 220 1311
VFD450C23A-00
VFD450C23A-21
228 73 301 387 124 511 1251 267 1518
VFD550C23A-00
VFD550C23A-21
228 73 301 387 124 511 1401 308 1709
VFD750C23A-00
VFD750C23A-21
246 73 319 418 124 542 1770 369 2139
VFD900C23A-00
VFD900C23A-21
224 112 336 381 190 571 2304 484 2788
VFD007C43A-21
VFD007C4EA-21
- - - - - - 33 25 59
VFD015C43A-21
VFD015C4EA-21
- - - - - - 45 29 74
VFD022C43A-21
VFD022C4EA-21
14 - 14 24 - 24 71 33 104
VFD037C43A-21
VFD037C4EA-21
10 - 10 17 - 17 103 38 141
VFD040C43A-21
VFD040C4EA-21
10 - 10 17 - 17 116 42 158
VFD055C43A-21
VFD055C4EA-21
10 - 10 17 - 17 134 46 180
VFD075C43A-21
VFD075C4EA-21
40 14 54 68 24 92 216 76 292
VFD110C43A-21
VFD110C4EA-21
66 14 80 112 24 136 287 93 380
VFD150C43A-21
VFD150C4EA-21
58 14 73 99 24 124 396 122 518
VFD185C43A-21
VFD185C4EA-21
99 21 120 168 36 204 369 138 507
VFD220C43A-21
VFD220C4EA-21
99 21 120 168 36 204 476 158 635
VFD300C43A-21
VFD300C4EA-21
126 21 147 214 36 250 655 211 866
VFD370C43S-00
VFD370C43S-21
179 30 209 304 51 355 809 184 993
VFD450C43S-00
VFD450C43S-21
179 30 209 304 51 355 929 218 1147
VFD550C43A-00
VFD550C43A-21
179 30 209 304 51 355 1156 257 1413
VFD750C43A-00
VFD750C43A-21
186 30 216 316 51 367 1408 334 1742

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
