Delta C2000 Plus Series User Manual

Chapter 2 InstallationC2000 Plus
2-6
Model No.
Airflow Rate for Cooling
Power Dissipation for
AC Motor Drive
Flow Rate (Unit: cfm) Flow Rate (Unit: m
3
/ hr) Power Dissipation (Unit: watt)
External Internal Total External Internal Total
Loss External
(Heat sink)
Internal Total
VFD900C43A-00
VFD900C43A-21
257 73 330 437 124 561 1693 399 2092
VFD1100C43A-00
VFD1100C43A-21
223 73 296 379 124 503 2107 491 2599
VFD1320C43A-00
VFD1320C43A-21
224 112 336 381 190 571 2502 579 3081
VFD1600C43A-00
VFD1600C43A-21
289 112 401 491 190 681 3096 687 3783
VFD1850C43A-00
VFD1850C43A-21
454 771 4589
VFD2000C43A-00
VFD2000C43A-21
454 771 5050
VFD2200C43A-00
VFD2200C43A-21
454 771 5772
VFD2500C43A-00
VFD2500C43A-21
454 771 6063
VFD2800C43A-00
VFD2800C43C-21
769 1307 6381
VFD3150C43A-00
VFD3150C43C-21
769 1307 7156
VFD3550C43A-00
VFD3550C43C-21
769 1307 8007
VFD4000C43A-00
VFD4000C43C-21
769 1307 9025
VFD4500C43A-00
VFD4500C43C-21
769 1307 11894
VFD5000C43A-00
VFD5000C43C-21
952.9 1618.9 12500
VFD5600C43A-00
VFD5600C43C-21
952.9 1618.9 14350
VFD015C53A-21 - - - - - - 39.5 13.0 53
VFD022C53A-21 - - - - - - 55.0 22.0 77
VFD037C53A-21 0.006 - 0.006 13.6 - 13.6 86.8 42.7 130
VFD055C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 124.6 67.9 193
VFD075C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 143.5 119.0 263
VFD110C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 222.2 162.8 385
VFD150C53A-21 0.019 0.007 0.026 40.0 14.5 54.5 308.5 216.5 525
VFD185C63B-21 90.0 21.3 111.4 153.0 36.2 189.2 317.5 145.0 462.5
VFD220C63B-21 90.0 21.3 111.4 153.0 36.2 189.2 408.2 141.8 550.0
VFD300C63B-21 90.0 21.3 111.4 153.0 36.2 189.2 492.7 257.3 750.0
VFD370C63B-21 89.0 21.3 110.3 151.2 36.2 187.5 641.6 283.4 925.0
VFD450C63B-00
VFD450C63B-21
175.9 36.4 212.3 298.8 61.8 360.6 718.2 406.8 1125.0
VFD550C63B-00
VFD550C63B-21
175.9 36.4 212.3 298.8 61.8 360.6 890.1 484.9 1375.0
VFD750C63B-00
VFD750C63B-21
264.6 90.6 355.2 449.6 153.9 603.5 1356.0 519.0 1875.0
VFD900C63B-00
VFD900C63B-21
264.6 90.6 355.2 449.6 153.9 603.5 1652.8 597.2 2250.0
VFD1100C63B-00
VFD1100C63B-21
264.6 90.6 355.2 449.6 153.9 603.5 1960.3 789.7 2750.0
VFD1320C63B-00
VFD1320C63B-21
264.6 90.6 355.2 449.6 153.9 603.5 2230.8 1069.2 3300.0
VFD1600C63B-00
VFD1600C63B-21
248.1 135.3 383.4 421.6 229.9 651.4 2627.3 1372.7 4000.0
