7-6 EMC Filter
Following table is the external EMC filter of C2000 Plus series, user can choose corresponding zero
phase reactor and suitable shielded cable length in accord to required noise emission and electromagnetic
interference level to have the best configuration to suppress the electromagnetic interference. When the
application does not consider RE and only needs CE to comply with C2 or C1, there is no need to install
zero phase reactor in input side.
230V models
C2000 Plus
Filter model name
Zero phase reactor
Fc
Conducted
Emission
(CE)
Radiation
Emission
(RE)
Frame Model
Rated input
current (A)
Input side
(R / S / T)
Output side
(U / V / W)
Output
shielded
cable length
EN61800-3
C2 C1
A
VFD007C23A-21 6.4
EMF021A23A
RF008X00A
or
T60006L2040W453
RF008X00A
or
T60006L2040W453
≤ 8 kHz
100 m 50 m C2
VFD015C23A-21 12
VFD022C23A-21 16
VFD037C23A-21 20
B
VFD055C23A-21 28
EMF056A23A
RF004X00A
or
T60006L2050W565
RF004X00A
or
T60006L2050W565
VFD075C23A-21 36
VFD110C23A-21 52
C
VFD150C23A-21 72
KMF3100A
RF002X00A
or
T60006L2160V066
RF002X00A
or
T60006L2160V066
≤ 6 kHz
VFD185C23A-21 83
VFD220C23A-21 99
D
VFD300C23A-00
VFD300C23A-21
124
B84143D0150R127 N/A
VFD370C23A-00
VFD370C23A-21
143
E
VFD450C23A-00
VFD450C23A-21
171
B84143B0250S020
N/A
RF300X00A
or
T60006L2160V066
≤ 4 kHz
VFD550C23A-00
VFD550C23A-21
206
VFD750C23A-00
VFD750C23A-21
245
F
VFD900C23A-00
VFD900C23A-21
331 B84143B0400S020
Table 7-77
