Delta C2000 Plus Series User Manual

Chapter 7 Optional AccessoriesC2000 Plus
7-12
Non-fuse Circuit Breaker
Comply with the UL standard: Per UL 508, paragraph 45.8.4, part a.
The rated current of the non-fuse circuit breaker should be 1.6–2.6 times (575V / 690V models: 2–4 times)
the drive’s rated input current.
230V / Three-phase 460V / Three-phase
Model
Breaker Rated
Input
Recommended
Current (A)
Model
Breaker Rated
Input
Recommended
Current (A)
VFD007C23A-21 15 VFD007C43A-21 / VFD007C4EA-21 10
VFD015C23A-21 20 VFD015C43A-21 / VFD015C4EA-21 10
VFD022C23A-21 30 VFD022C43A-21 / VFD022C4EA-21 15
VFD037C23A-21 40 VFD037C43A-21 / VFD037C4EA-21 20
VFD055C23A-21 50 VFD040C43A-21 / VFD040C4EA-21 20
VFD075C23A-21 70 VFD055C43A-21 / VFD055C4EA-21 40
VFD110C23A-21 110 VFD075C43A-21 / VFD075C4EA-21 40
VFD150C23A-21 125 VFD110C43A-21 / VFD110C4EA-21 50
VFD185C23A-21 150 VFD150C43A-21 / VFD150C4EA-21 70
VFD220C23A-21 200 VFD185C43A-21 / VFD185C4EA-21 80
VFD300C23A-00 / VFD300C23A-21 250 VFD220C43A-21 / VFD220C4EA-21 100
VFD370C23A-00 / VFD370C23A-21 300 VFD300C43A-21 / VFD300C4EA-21 125
VFD450C23A-00 / VFD450C23A-21 350 VFD370C43S-00 / VFD370C43S-21 150
VFD550C23A-00 / VFD550C23A-21 400 VFD450C43S-00 / VFD450C43S-21 175
VFD750C23A-00 / VFD750C23A-21 500 VFD550C43A-00 / VFD550C43A-21 250
VFD900C23A-00 / VFD900C23A-21 600 VFD750C43A-00 / VFD750C43A-21 300
VFD900C43A-00 / VFD900C43A-21 350
VFD1100C43A-00 / VFD1100C43A-21 400
VFD1320C43A-00 / VFD1320C43A-21 500
VFD1600C43A-00 / VFD1600C43A-21 600
VFD1850C43A-00 / VFD1850C43A-21 600
VFD2000C43A-00 / VFD2000C43A-21 800
VFD2200C43A-00 / VFD2200C43A-21 800
VFD2500C43A-00 / VFD2500C43A-21 1000
VFD2800C43A-00 / VFD2800C43C-21 1000
VFD3150C43A-00 / VFD3150C43C-21 1200
VFD3550C43A-00 / VFD3550C43C-21 1350
VFD4000C43A-00 / VFD4000C43C-21 1500
VFD4500C43A-00 / VFD4500C43C-21 1600
VFD5000C43A-00 / VFD5000C43C-21 2000
VFD5600C43A-00 / VFD5600C43C-21 2000
Table 7-12
Table 7-11

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
