Delta C2000 Plus Series User Manual

Appendix A. Modbus ProtocolC2000 Plus
A-12
6. Status monitor read only (22xx): communication station address is Pr.09-00 setting value
Function
Name
Modbus
Address
Attribute
(Function
Code)
Size Description
Output
current
2200H R(03H)
U16
Display output current (A). When current is higher than 655.35,
it shifts the decimal as (XXX.X A). The decimal can refer to High
byte of 211F.
Counter
value
2201H R(03H) Display counter value (c)
Output
frequency
2202H R(03H) Actual output frequency (XXXXX Hz)
DC bus
voltage
2203H R(03H)
U16
DC bus voltage (XXX.X V)
Output
voltage
2204H R(03H) Output voltage (XXX.X V)
Power
factor angle
2205H R(03H) Power angle (XXX.X)
Power
output
2206H R(03H) Display actual motor speed kW of U, V, W (XXXX.X kW)
Motor
actual
speed
2207H R(03H)
Display motor speed in rpm estimated by the drive or encoder
feedback (XXXXX rpm)
Output
torque
2208H R(03H)
Display positive/negative output torque in %, estimated by the
drive (t0.0: positive torque, -0.0: negative torque) (XXX.X %)
Feedback
position
2209H R(03H) Display PG feedback (see NOTE 1 in Pr.00-04)
PID
feedback
value
220AH R(03H) PID feedback value after enabling PID function (XXX.XX %)
AVI analog
input
220BH R(03H)
Display signal of AVI analog input terminal, 0–10 V corresponds
to 0.00–100.00% (1.) (see NOTE 2 in Pr.00-04)
ACI analog
input
220CH R(03H)
Display signal of ACI analog input terminal, 4–20 mA / 0–10 V
corresponds to 0.00–100.00% (2.) (see NOTE 2 in Pr.00-04)
AUI analog
input
220DH R(03H)
Display signal of AUI analog input terminal, -10 V–10 V
corresponds to -100.00–100% (3.) (see NOTE 2 in Pr.00-04)
IGBT
temperature
220EH R(03H) IGBT temperature of drive power module (XXX.XºC)
Drive
capacitance
temperature
220FH R(03H) The temperature of capacitance (XXX.XºC)
Digital input
status
2210H R(03H)
The status of digital input (ON/OFF), refer to Pr.02-12
(see NOTE 3 in Pr.00-04)
Digital
output
status
2211H R(03H)
The status of digital output (ON/OFF), refer to Pr.02-18
(see NOTE 4 in Pr.00-04)
Multi-step
speed
2212H R(03H) The multi-step speed that is executing (S)
