Chapter 7 Optional AccessoriesC2000 Plus
7-59
460V
Rated current
(HD, Arms)
Without an AC output reactor With an AC output reactor
Built-in EMC Filter drive
model
Shielded Cable
(meter)
Non-shielded
cable (meter)
Shielded Cable
(meter)
Non-shielded
cable (meter)
VFD007C4EA-21 3 30 75 30 115
VFD015C4EA-21 4 30 75 30 115
VFD022C4EA-21 6 30 75 30 115
VFD037C4EA-21 9 30 75 30 115
VFD040C4EA-21 10.5 30 75 30 115
VFD055C4EA-21 12 30 75 30 115
VFD075C4EA-21 18 50 150 50 225
VFD110C4EA-21 24 50 150 50 225
VFD150C4EA-21 32 50 150 50 225
VFD185C4EA-21 38 50 150 50 225
VFD220C4EA-21 45 50 150 50 225
VFD300C4EA-21 60 50 150 50 225
575V
kW HP
Rated
Current
Without an AC output reactor With an AC output reactor
Model
Normal
Duty
(Arms)
Shielded
Cable
(meter)
Non-shielded
Cable (meter)
Shielded
Cable
(meter)
Non-shielded
Cable (meter)
VFD015C53A-21 1.5 2 2.5 30 35 20 45
VFD022C53A-21 2.2 3 3.6 30 35 20 45
VFD037C53A-21 3.7 5 5.5 30 35 20 45
VFD055C53A-21 5.5 7.5 8.2 30 35 20 45
VFD075C53A-21 7.5 10 10 30 35 20 45
VFD110C53A-21 11 15 15.5 30 35 20 45
VFD150C53A-21 15 20 20 30 35 20 45
690V
kW HP
Rated
Current
Without AC reactor With AC reactor
Model
Normal
Duty
(Arms)
Shielded
Cable
(meter)
Non-shielded
Cable (meter)
Shielded
Cable
(meter)
Non-shielded
Cable (meter)
VFD185C63B-21
18.5 25
20 20 35 30 45
VFD220C63B-21
22 30
24 20 35 30 45
VFD300C63B-21
30 40
30 20 35 45 60
VFD370C63B-21
37 50
36 20 45 60 75
VFD450C63B-00/21
45 60
45 20 45 60 75
VFD550C63B-00/21
55 75
54 20 45 60 100
VFD750C63B-00/21
75 100
67 20 45 60 100
VFD900C63B-00/21
90 125
86 20 45 75 100
VFD1100C63B-00/21
110 150
104 20 45 75 100
VFD1320C63B-00/21
132 175
125 20 45 75 100
VFD1600C63B-00/21
160 215
150 20 45 90 100
VFD2000C63B-00/21
200 270
180 20 45 90 100
VFD2500C63B-00/21
250 335
220 20 45 90 100
VFD3150C63B-00/21
315 425
290 20 45 90 100
VFD4000C63B-00/21
400 530
350 20 45 90 100
Table 7-65
Table 7-66
