Delta C2000 Plus Series

Chapter 7 Optional AccessoriesC2000 Plus
7-74
690V models
Frame Model Filter model name Zero phase reactor
Conducted and radiated emission
(CE, RE)
C2-motor cable
length-50m
C3-motor cable
length-100m
Location of zero phase reactor
(See figure below)
1* 2* 3* 1* 2* 3*
A
VFD015C53A-21
EMF014A63A
T60006L2040W453
1
1
VFD022C53A-21 1 1
VFD037C53A-21 1 1
B
VFD055C53A-21
EMF027A63A
1 1
1 1
VFD075C53A-21 1 1 1 1
VFD110C53A-21 1 1 1 1
VFD150C53A-21 1 1 1 1
C
VFD185C63B-21
B84143A0050R021
T60006L2050W565
VFD220C63B-21
VFD300C63B-21
VFD370C63B-21
D
VFD450C63B-00
B84143A0080R021
1 2
VFD550C63B-00 1 2
VFD450C63B-21 1 2
VFD550C63B-21 1 2
E
VFD750C63B-00
B84143B0150S021
T60006L2160V066
VFD900C63B-00
VFD1100C63B-00
VFD1320C63B-00
VFD750C63B-21
VFD900C63B-21
VFD1100C63B-21
VFD1320C63B-21
F
VFD1600C63B-00
B84143B0250S021
VFD2000C63B-00
VFD1600C63B-21
VFD2000C63B-21
G
VFD2500C63B-00
B84143B0400S021
VFD3150C63B-00
VFD2500C63B-21
VFD3150C63B-21
H
VFD4000C63B-00
B84143B1000S021
1 1
VFD4500C63B-00 1 1
VFD5600C63B-00 1 1
VFD6300C63B-00 1 1
VFD4000C63B-21 1 1
VFD4500C63B-21 1 1
VFD5600C63B-21 1 1
VFD6300C63B-21 1 1
Table 7-81
NOTE: The number represents quantity of zero phase reactor, all the motor cable are shielded cables.
