Chapter 7 Optional AccessoriesC2000 Plus
7-112
Frame C
Applicable models
VFD150C23A-21; VFD185C23A-21; VFD220C23A-21
Capacitor Fan Model “MKC-CFKB1”
Figure 7-128
Frame C
Applicable models
VFD185C43A-21; VFD220C43A-21; VFD300C43A-21;
VFD185C4EA-21; VFD220C4EA-21; VFD300C4EA-21
Capacitor Fan Model “MKC-CFKB2”
Figure 7-129
Frame C
 Following models use one set of MKC-CFKM:
VFD185C43A-21; VFD220C43A-21; VFD300C43A-21;
VFD185C4EA-21; VFD220C4EA-21
 Following models use two sets of MKC-CFKM:
VFD150C23A-21; VFD185C23A-21; VFD220C23A-21;
VFD300C4EA-21
Heat sink Fan “MKC-CFKM”
Figure 7-130
Frame C
Applicable models
VFD185C63B-21; VFD220C63B-21; VFD300C63B-21;
VFD370C63B-21
Heat sink Fan
“MKC-CFKM1”
Figure 7-131
Capacitor Fan
“MKC-CFKB3”
Figure 7-132
Frame D0
Applicable models
VFD370C43S-00; VFD450C43S-00; VFD370C43S-21;
VFD450C43S-21
Heat sink Fan Model
“MKC-D0FKM”
Figure 7-133
Capacitor Fan Model
”MKC-DFKB”
Figure 7-134
