Delta C2000 Plus Series User Manual

Chapter 9 Specification C2000 Plus
9-5
Frame Size G H
VFD-_ _ _ C_ _ _-21 / -00
1850 2000 2200 2500 2800 3150 3550 4000 4500 5000 5600
Output Rating*
Heavy duty
Rated Output Capacity (kVA)
295 315 367 383 438 491 544 613 690 741 872
Rated Output Current (A)
370 395 460 481 550 616 683 770 866 930 1094
Applicable Motor Output (kW)
185 200 220 250 280 315 355 400 450 500 560
Applicable Motor Output (HP)
250 270 300 340 375 420 475 530 600 675 750
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
180% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–9 (Default: 4)
Super Heavy Duty
Rated Output Capacity (kVA)
247 247 295 315 366 438 491 544 544 690 741
Rated Output Current (A)
310 310 370 395 460 550 616 683 683 866 930
Applicable Motor Output (kW)
160 160 185 200 220 280 315 355 355 450 500
Applicable Motor Output (HP)
215 215 250 270 300 375 425 475 475 600 675
Overload Capacity
150% of rated output current: 1 minute for every 5 minutes;
200% of rated output current: 3 seconds for every 30 seconds
Max. Output Frequency (Hz)
0.00–599.00
Carrier Frequency (kHz)
2–9 (Default: 4) 2–9 (Default: 3)
Input Rating
Input Current
(A)
Heavy Duty 380 395 400 447 494 555 625 770 866 930 1094
Super Heavy Duty 300 300 380 390 400 494 555 590 625 866 930
Rated Voltage / Frequency
3-phase AC 380–480V (-15 % – +10 %), 50 / 60 Hz
Operating Voltage Range
323–528 V
AC
Frequency Tolerance
47–63 Hz
Power Supply
Capacity (kVA)
Heavy Duty
315.9 328.4 332.5 371.6 410.7 461.4 519.6 640.1 720.0 773.2 909.5
Super Heavy Duty 249.4 249.4 315.9 324.2 332.5 410.7 461.4 490.5 519.6 720.0 773.2
Efficiency (%)
98.2
Displacement Power Factor (cosθ)
>0.98
Drive Weight (Kg)
134 ± 4 228
Cooling Method
Fan cooling
Braking Chopper
Frame G–H: Optional
DC choke Frame G–H: Built-in
EMC Filter Frame G–H: Optional
EMC-COP01
Frame G–H (VFDxxxC43A-00): Optional
Frame G–H (VFDxxxC43A-21): Built-in
Table 9-4
NOTE:
1. * : The factory setting is heavy duty mode.
2. The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Refer to Section
9-7 Derating Curve for details.
3. The AC motor drive should operate in derating current when its control method is set to FOC Sensorless,
TQC+PG, TQC sensorless. PM+PG, PM sensorless Please refer to Pr. 06-55 for more information.
4. The rated input current will be affected by not only power transformer and the connection of the reactors on input
side, but also fluctuates with the impedance of power side.
5. Model VFD4500C43x-xx, VFD5000C43x-xx, VFD5600C43x-xx do not have UL certification.
6. Rated output capacity is calculated by 460 V
AC
, it is as a reference for the mains power drive capacity selection.
