Delta C2000 Plus Series User Manual

Chapter 9 Specification C2000 Plus
9-9
General Specifications
Item Specifications
Control Characteristics
Control Mode*
1
230V
AC
／460V
AC
models
Select a control mode listed below via parameter,
 IMVF (Induction Motor, V/F control)
 IMVF＋PG (Induction Motor, V/F control, with encoder)
 IM／PM SVC (Induction Motor / Permanent-Magnet Synchronous Motor,
Space Vector Control)
 IMFOC＋PG (Induction Motor, Field-Oriented Control, with encoder)
 PMFOC＋PG (Permanent-Magnet Synchronous Motor, Field-Oriented
Control, with encoder)
 IMFOC Sensorless (Induction Motor, sensorless Field-Oriented Control)
 PM Sensorless (Permanent-Magnet Synchronous Motor, sensorless
Field-Oriented Control)
 IPM Sensorless (Interior Permanent-Magnet Synchronous Motor, sensorless
Field-Oriented Control)
 SynRM Sensorless (Synchronous Reluctance Motor, sensorless
Field-Oriented Control)
 IM TQCPG (Induction Motor, Torque Control, with encoder)
 PM TQCPG (Permanent-Magnet Synchronous Motor, Torque Control, with
encoder)
 IM TQC Sensorless (Induction Motor, sensorless Torque Control)
 SynRM TQC Sensorless (Synchronous Reluctance Motor, sensorless Torque
Control)
575V
AC
／690V
AC
models
Select a control mode listed below via parameter,
 IMVF (Induction Motor, V/F control)
 IMVF＋PG (Induction Motor, V/F control, with encoder)
 IM／PM SVC (Induction Motor / Permanent-Magnet Synchronous Motor,
Space Vector Control)
Max. Output
Frequency*
2
0–599 Hz
Frequency Output
Accuracy
Digital command: ±0.01% of the maximum output frequency (Pr.01-00),
-10°C– +40°C;
Analog command: ±0.1% of the maximum output frequency (Pr.01-00),
25±10°C
Frequency Setting
Resolution
Digital command: 0.01 Hz；
Analog command: 0.05% x max. output frequency (Pr.01-00), 11 bit plus sign
Speed Control Range
(Ratio of Speed
control)*
3
 IMVF, IMVF＋PG, IMSVC 1:50
 IMFOC Sensorless 1:100
 IMFOC＋PG 1:1000
 PMSVC 1:20
 PM Sensorless 1:50
 IPM Sensorless 1:100
 PMFOC＋PG 1:1000
Starting Torque
 IMVF, IMVF＋PG, IMSVC 150% / 3 Hz
 IMFOC Sensorless 200% / 0.5 Hz
 IMFOC＋PG 200% / 0 Hz

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
