Delta C2000 Plus Series User Manual

Chapter 11 Summary of Parameter SettingsC2000 Plus
11-7
Pr. Parameter Name Setting Range Default
00-16 Duty Selection
230V / 460V models
0: Heavy duty
1: Super Heavy duty
0
575V / 690V models
0: Normal duty
1: Heavy duty
2: Light duty
2
00-17 Carrier Frequency (kHz)
Heavy duty
Control mode
Model
VF,
SVC
VFPG
IMFOC
PG,
IMTQC
PG
PMFOC
PG,
PMTQC
PG
PMFOC,
IPMFOC
IMFOC,
IMTQC
SRM
FOC*
VFD007–110C23A/E
VFD007–150C43A/E
2–15 2–10 2–8 4–8 4–10 4–12 4–8
VFD150–370C23A/E
VFD185–550C43A/E
2–10 2–10 2–8 4–8 4–10 4–10 4–8
VFD450–900C23A/E
VFD750–5600C43A/E
2–9 2–9 2–8 4–8 4–9 4–9 4–8
*The default for SRMFOC is 4 kHz.
8
6
4
Super Heavy duty
Control mode
Model
VF,
SVC
VFPG
IMFOC
PG,
IMTQC
PG
PMFOC
PG,
PMTQC
PG
PMFOC,
IPMFOC
IMFOC,
IMTQC
SRM
FOC*
VFD007–110C23A/E
VFD007–150C43A/E
2–15 2–10 2–8 4–8 4–10 4–12 4–8
VFD150–450C23A/E
VFD185–550C43A/E
2–10 2–10 2–8 4–8 4–10 4–10 4–8
VFD550–900C23A/E
VFD750–3150C43A/E
2–9 2–9 2–8 4–8 4–9 4–9 4–8
VFD3550–5600C43A
VFD3550–5600C43E
2–9 2–9 2–8 4–8 4–9 4–9 4–8
*The default for SRMFOC is 4 kHz.
4
4
4
3
575V/690V (Light / Heavy / Super Heavy duty)
Power/ Control mode VF, VFPG, SVC
1–15 HP (575V) 2–15 kHz
20–600 HP (690V) 2–9 kHz
850 HP (690V) 2–9 kHz
6
4
3
00-19 PLC Command Mask
bit0: Control command is forced by PLC control
bit1: Frequency command is forced by PLC control
bit2: Position command is forced by PLC control
bit3: Torque command is forced by PLC control
Read
only
00-20
Master Frequency Command
Source (AUTO) / Source
Selection of the PID Target
0: Digital keypad
1: RS-485 communication input
2: External analog input (Refer to Pr.03-00–03-02)
3: External UP / DOWN terminal (multi-function input
terminals)
0
