Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-01-4
 5: You can return the kWh displayed value to 0 even during drive operation. For example, you can
set Pr.05-26–Pr.05-30 to 0.
 6: Clear the internal PLC program (includes the related settings of PLC internal CANopen master)
 7: Reset the related settings of CANopen slave.
 9 or 10: Reset all parameters to defaults. If you have set a password (Pr.00-08), unlock the
password (Pr.00-07) to clear the password you have set before you reset all parameters.
 For settings of 6, 7, 9, 10, you must reboot the motor drive after you finish the setting.

00-03
Start-Up Display
Default: 0
Settings 0: F (frequency command)
1: H (output frequency)
2: U (user-defined, see Pr.00-04)
3: A (output current)
 Determines the start-up display page after power is applied to the drive. The user-defined
contents display according to the Pr.00-04 settings.

00-04
Content of Multi-Function Display (User-Defined)
Default: 3
Settings 0: Display output current (A) (unit: Amp)
1: Display counter value (c) (Unit: CNT)
2: Display the motor’s actual output frequency (H.) (Unit: Hz)
3: Display the drive’s DC bus voltage (v) (Unit: V
DC
)
4: Display the drive’s output voltage (E) (Unit: V
AC
)
5: Display the drive’s output power angle (n) (Unit: deg)
6: Display the drive’s output power (P) (Unit: kW)
7: Display the motor speed rpm (r) (Unit: rpm)
8: Display the drive’s estimated output torque, motor’s rated torque is 100%
(t) (Unit: %)
9: Display PG feedback (G) (refer to Pr.10-00 and Pr.10-01) (Unit: PLS)
10: Display PID feedback (b) (Unit: %)
11: Display AVI analog input terminal signal (1.) (Unit: %)
12: Display ACI analog input terminal signal (2.) (Unit: %)
13: Display AUI analog input terminal signal (3.) (Unit: %)
14: Display the drive’s IGBT temperature (i.) (Unit: °C)
15: Display the drive’s capacitance temperature (c.) (Unit: °C)
16: The digital input status (ON / OFF) (i)
17: The digital output status (ON / OFF) (o)
18: Display multi-step speed (S)
19: The corresponding CPU digital input pin status (d)
20: The corresponding CPU digital output pin status (0.)

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
