Delta C2000 Plus Series User Manual

Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-01-17
Point-to-point positioning control diagram:
Point-to-point (P2P) positioning position control:
 The P2P position control is a positioning function that controls the motor operation from one
position to another. This function controls the positioning position according to the encoder
feedback signals, and determines the positioning position through the multi-function input
terminals. A maximum of four multi-function input terminals can be used at the same time to
switch between 15 positions.

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
