Delta C2000 Plus Series - Page 47

Chapter 3 UnpackingC2000 Plus
3-4
Frame F
Unpacking 1
(VFDXXXCXXA-00, VFDXXXC63B-00)
Unpacking 2
(VFDXXXCXXA-21, VFDXXXC63B-21)
Remove the six buckles fixed on the crate with a
flat-head screwdriver, see the figure below.
Remove the six buckles fixed on the crate with a
flat-head screwdriver, see the figure below.
Remove the top cover, take out the EPEs and the
manual.
Remove the top cover, take out the EPEs, rubber
and the manual.
Figure 3-9
Figure 3-10
Figure 3-13
Figure 3-14
