Delta C2000 Plus Series User Manual

Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-05-4
05-18
Stator Resistance (Rs) for Induction Motor 2
Default: Depending on the
model power
Settings 0.000–65.535 W
05-19
Rotor Resistance (Rr) for Induction Motor 2
Default: Depending on the
model power
Settings 0.000–65.535 W
05-20
Magnetizing Inductance (Lm) for Induction Motor 2
Default: Depending on the
model power
Settings 0.0–6553.5 mH
05-21
Stator Inductance (Lx) for Induction Motor 2
Default: Depending on the
model power
Settings 0.0–6553.5 mH
05-22
Induction Motor 1 / 2 Selection
Default: 1
Settings 1: Motor 1
2: Motor 2
 Set the motor currently operated by the AC motor drive.

05-23
Frequency for Y-Connection / ∆-Connection Switch for an Induction Motor
Default: 60.00
Settings 0.00–599.00 Hz
05-24
Y-Connection / ∆-Connection Switch for an Induction Motor
Default: 0
Settings 0: Disabled
1: Enabled

05-25
Delay Time for Y-Connection / ∆-Connection Switch for an Induction Motor
Default: 0.200
Settings 0.000–60.000 sec.
 You can apply Pr.05-23–Pr.05-25 in a wide range of motors, and the motor coil executes the Y-
connection / -connection switch as required. The wide range motors are related to the motor
design. In general, the motor has higher torque with low speed Y-connection, and has higher
speed with high speed -connection).
 Pr.05-24 enables and disables the switch of Y-connection / -connection.
 When you set Pr.05-24 as 1, the drive uses the Pr.05-23 setting and current motor frequency, and
