Chapter 3 UnpackingC2000 Plus
3-26
H1
VFD2800C43A-00; VFD3150C43A-00; VFD3550C43A-00; VFD4000C43A-00; VFD4500C43A-00: 244 kg /
(537.9 lbs)
VFD5000C43A-00; VFD5600C43A-00: 270 kg / (595.2 lbs)
VFDXXXC63B-00: 243.0 kg / (535.7 lbs)
Figure 3-79
H2
VFDXXXC63B-21: 251.0 kg / (553.5 lbs)
Figure 3-80
H3
VFD2800C43C-21; VFD3150C43C-21; VFD3550C43C-21; VFD4000C43C-21; VFD4500C43C-21: 269 kg /
(593.0 lbs)
VFD5000C43C-21; VFD5600C43C-21: 295kg / (650.4 lbs)
Figure 3-81
