Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-13-4
Group setting 10: Air Handling Unit, AHU
The following table lists the relevant AHU setting application parameters.
Pr Explanation Settings
00-04 Content of Multi-Function Display 2
00-11 Speed Control Mode 0 (V/F control)
00-16 Duty Selection 0 (Normal load)
00-20
Master Frequency Command Source
(AUTO) / Source Selection of The PID
Target
2 or 0
00-21 Operation Command Source (AUTO) 1 or 0
00-22 Stop Method 1 (Coast to stop)
00-23 Control of Motor Direction 1 (Disable reverse)
00-30
Master Frequency Command (HAND)
Source
0 (Digital keypad)
00-31 Operation Command (HAND) Source 0 (Digital keypad)
01-00 Maximum Operation Frequency 50
01-01 Motor 1 Rated / Base Frequency 50
01-02 Motor 1 Rated / Base Output Voltage 380
01-07 Motor 1 Minimum Output Frequency 0.1
01-10 Output Frequency Upper Limit 50
01-11 Output Frequency Lower Limit 35
01-34 Zero-Speed Mode 2
01-43 V/F Curve Selection 2
02-05 Multi-Function Input Command 5 (MI5) 16 or 17
02-13 Multi-Function Output 1 RLY1 11
02-14 Multi-Function Output 2 RLY2 1
03-00 Analog Input Selection (AVI) 1
03-01 Analog Input Selection (ACI) 1
03-02 Analog Input Selection (AUI) 1
03-28 AVI Terminal Input Selection 0
03-29 ACI Terminal Input Selection 1
03-20 Multi-Function Output 1 (AFM1) 0
03-23 Multi-Function Output 2 (AFM2) 0
03-31 AFM2 Output Selection 0 or 1
03-50 Analog Input Curve Selection 4 (three-point curve of AUI)
07-06 Restart after Momentary Power Loss
2 (Speed tracking by minimum output
frequency)
07-11 Number of Times of Restart after Fault 5 (times)
07-33 Auto-Restart Interval of Fault 60 (s)
