Delta C2000 Plus Series User Manual

Chapter 5 Main Circuit TerminalsC2000 Plus
5-14
Frame E
R/L1 T/L3 V/T2S/L2 U/T1 W/T3
 If you install at Ta 40°C (for 230V / 460V model names with last digit -21; for 690V model names
end with 63B-21)
/ 50°C (for 230V / 460V model names with last digit -00; for 690V model names
end with 63B-00)
environment, use copper wires have a voltage rating of 600V and are
temperature resistance to 75°C
or 90°C.
 If you install at Ta 40°C (for 230V / 460V model names with last digit -21; for 690V model names
end with 63B-21)
/ 50°C (for 230V / 460V model names with last digit -00; for 690V model names
end with 63B-00) above environment, use copper wires have a voltage rating of 600V and are
temperature resistant ntance to 90°C or above.
 To be UL installation compliant, you must use copper wires when installing. The wire gauge is
based on temperature resistance of 75°C, in accordance with
UL requirements and
recommendations. Do not reduce the wire gauge when using high-temperature resistant wire.
Model Name
Main Circuit Terminals
R/L1、S/L2、T/L3、U/T1、V/T2、W/T3、
-/DC-、+1/DC+
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
VFD450C23A-00
120 mm
2
*2
(4/0 AWG*2)
50 mm
2
*2 (1/0 AWG*2)
M8
180 kg-cm
(156.2 lb-in.)
(17.65 Nm)
50mm
2
*2 (1/0 AWG*2) 50 mm
2
*1 (1/0 AWG*1)
M8
180 kg-cm
(156.2 lb-in.)
(17.65 Nm)
VFD550C23A-00 95 mm
2
*2 (3/0 AWG*2) 95mm
2
*2 (3/0 AWG*2) 95 mm
2
*1 (3/0 AWG*1)
VFD750C23A-00 120 mm
2
*2 (4/0 AWG*2)
120mm
2
*2 (4/0 AWG*2)
120 mm
2
*1 (4/0 AWG*1)
VFD900C43A-00 50 mm
2
*2 (1/0 AWG*2) 50mm
2
*2 (1/0 AWG*2) 50 mm
2
*1 (1/0 AWG*1)
VFD1100C43A-00 95 mm
2
*2 (3/0 AWG*2) 95mm
2
*2 (3/0 AWG*2) 95 mm
2
*1 (3/0 AWG*1)
VFD450C23A-21 50 mm
2
*2 (1/0 AWG*2) 50mm
2
*2 (1/0 AWG*2) 50 mm
2
*1 (1/0 AWG*1)
VFD550C23A-21 70 mm
2
*2 (2/0 AWG*2) 70mm
2
*2 (2/0 AWG*2) 70 mm
2
*1 (2/0 AWG*1)
VFD750C23A-21 95 mm
2
*2 (3/0 AWG*2) 95mm
2
*2 (3/0 AWG*2) 95 mm
2
*1 (3/0 AWG*1)
VFD900C43A-21 50 mm
2
*2 (1/0 AWG*2) 50mm
2
*2 (1/0 AWG*2) 50 mm
2
*1 (1/0 AWG*1)
VFD1100C43A-21 70 mm
2
*2 (2/0 AWG*2) 70mm
2
*2 (2/0 AWG*2) 70 mm
2
*1 (2/0 AWG*1)
VFD750C63B-00 25 mm
2
*2 (4 AWG*2)
25 mm
2
*2(4 AWG*2)
25 mm
2
*1 (4 AWG*1)
VFD900C63B-00 35 mm
2
*2 (2 AWG*2)
35 mm
2
*2 (2 AWG*2)
35 mm
2
*1 (2 AWG*1)
VFD1100C63B-00 35 mm
2
*2 (2 AWG*2) 35 mm
2
*2 (2 AWG*2) 35 mm
2
*1 (2 AWG*1)
VFD1320C63B-00 50 mm
2
*2 (1/0 AWG*2)
50 mm
2
*2 (1/0 AWG*2)
50 mm
2
*1 (1/0 AWG*1)
VFD750C63B-21 25 mm
2
*2 (4 AWG*2)
25 mm
2
*2 (4 AWG*2)
25 mm
2
*1 (4 AWG*1)
VFD900C63B-21 35 mm
2
*2 (2 AWG*2)
35 mm
2
*2 (2 AWG*2)
35 mm
2
*1 (2 AWG*1)
VFD1100C63B-21 35 mm
2
*2 (2 AWG*2) 35 mm
2
*2 (2 AWG*2) 35 mm
2
*1 (2 AWG*1)
VFD1320C63B-21 50 mm
2
*2 (1/0 AWG*2)
50 mm
2
*2 (1/0 AWG*2)
50 mm
2
*1 (1/0 AWG*1)

Delta C2000 Plus Series Specifications

General

Altitude	Up to 1000m without derating
Communication	CANopen
Output Current	2.5A
Protection Features	Overcurrent, Overvoltage, Overtemperature
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Humidity	95% RH (non-condensing)
