Delta C2000 Plus Series User Manual

Chapter 14 Fault Codes and DescriptionsC2000 Plus
14-12
ID* Display on LCD Keypad Fault Name Fault Descriptions
8
Over-voltage during
deceleration
(ovd)
DC bus over-voltage during deceleration.
When ovd occurs, the drive closes the gate of the output
immediately, the motor runs freely, and the display
shows an ovd fault.
Action and Reset
Action condition
230V models: 410V
DC
460V models: 820V
DC
575V models: 1116V
DC
690V models: 1318V
DC
Action time Act immediately when DC bus voltage is higher than the condition
Fault treatment parameter N/A
Reset method Manual reset
Reset condition Reset only when DC bus voltage is lower than 90% of the over-voltage condition
Record Yes
Cause Corrective Actions
Deceleration time is too short,
causing too large regenerative
energy of the load
1. Increase the setting value of Pr.01-13, Pr.01-15, Pr.01-17 and Pr.01-
19
(deceleration time)
2. Connect brake resistor, brake unit or DC bus on the drive.
3. Reduce the brake frequency.
4. Replace the drive with a larger capacity model.
5. Use S-curve acceleration/deceleration.
6. Use over-voltage stall prevention (Pr.06-01).
7. Use auto-acceleration and auto-deceleration (Pr.01-44).
8. Adjust braking level (Pr.07-01 or the bolt position of the brake unit).
The setting for stall prevention
condition is smaller than no-load
current
The setting for stall prevention condition should be larger than no-load current
Power voltage is too high
Check if the input voltage is
within the rated AC motor drive input voltage range,
and check for possible voltage spikes.
ON/OFF switch action of phase-in
capacitor in the same power
system
If the phase-in capacitor or active power supply unit acts in the
same power
system,
the input voltage may surge abnormally in a short time. In this case,
install an AC reactor.
Motor ground fault
The ground
short circuit current charges the capacitor in the main circuit through
the power. Check if there is ground faul
t on the motor cable, wiring box and its
internal terminals.
Troubleshoot the ground fault.
Incorrect wiring of brake resistor or
brake unit
Check the wiring of brake resistor or brake unit.
Malfunction caused by
interference
Verify the wiring of the control circuit and wiring /
grounding of the main circuit to
prevent interference.
