Delta CP2000 Series User Manual

Chapter 6 Control TerminalsCP2000
6-3
 When the photo-coupler is using internal power supply, the switch connection for Sink
and Source as below:
MI-DCM: Sink mode
MI-+24V: Source mode
 When the photo-coupler is using external power supply, please remove the short circuit
cable between the +24V and COM terminals. The connection mode is Sink mode or
Source mode according to the below:
The “+” of 24V connecting to “COM: Sink mode
The “-“ of 24V connecting to COM: Source mode

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
