Chapter 7 Optional AccessoriesCP2000
7-14
380V–460V, 50 / 60 Hz
Model kW HP
Rated Amps
of AC Reactor
(Arms)
Max. continuous
Amps (Arms)
3%
Impedance
(mH)
5%
Impedance
(mH)
Built-in
DC
reactor
3%
Input AC reactor
Delta part #
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
VFD007CP43A-21/4EA-21
0.75 1 2.8 3 4.48 3.6 9.058 8.102 15.097 13.503 No
DR003A0810*
1
DR003A0810
VFD015CP43B-21/4EB-21
1.5 2 3 4.2 4.8 5.04 8.102 6.077 13.503 10.128 No
DR003A0810 DR004A0607
VFD022CP43B-21/4EB-21
2.2 3 4 5.5 6.4 6.6 6.077 4.05 10.128 6.75 No
DR004A0607 DR006A0405
VFD040CP43A-21/4EA-21
3.7 5 6 8.5 9.6 10.2 4.05 2.7 6.75 4.5 No
DR006A0405 DR009A0270
VFD037CP43B-21/4EB-21
4 5 9 10.5 14.4 12.6 2.7 2.315 4.5 3.858 No
DR009A0270 DR010A0231
VFD055CP43B-21/4EB-21
5.5 7.5 10.5 13 16.8 15.6 2.315 2.025 3.858 3.375 No
DR010A0231
DR012A0202
VFD075CP43B-21/4EB-21
7.5 10 12 18 19.2 21.6 2.025 1.35 3.375 2.25 No
DR012A0202
DR018A0117
VFD110CP43B-21/4EB-21
11 15 18 24 28.8 28.8 1.35 1.01 2.25 1.683 No
DR018A0117 DR024AP881
VFD150CP43B-21/4EB-21
15 20 24 32 38.4 38.4 1.01 0.76 1.683 1.267 No
DR024AP881 DR032AP660
VFD185CP43B-21/4EB-21
18.5 25 32 38 51.2 45.6 0.76 0.639 1.267 1.065 No
DR032AP660
DR038AP639
VFD220CP43A-21/4EA-21
22 30 38 45 60.8 54 0.639 0.541 1.065 0.902 No
DR038AP639 DR045AP541
VFD300CP43B-21/4EB-21
30 40 45 60 72 72 0.541 0.405 0.902 0.675 No
DR045AP541 DR060AP405
VFD370CP43B-21/4EB-21
37 50 60 73 96 87.6 0.405 0.334 0.675 0.557 No
DR060AP405 DR073AP334
VFD450CP43S-00/43S-21
45 60 73 91 116.8 109.2 0.334 0.267 0.557 0.445 Yes
DR073AP334 DR091AP267
VFD550CP43S-00/43S-21
55 75 91 110 145.6 132 0.267 0.221 0.445 0.368 Yes
DR091AP267 DR110AP221
VFD750CP43B-00/43B-21
75 100 110 150 176 180 0.221 0.162 0.368 0.27 Yes
DR110AP221 DR150AP162
VFD900CP43A-00/43A-21
90 125 150 180 240 216 0.162 0.135 0.27 0.225 Yes
DR150AP162 DR180AP135
VFD1100CP43A-00/43A-21
110 150 180 220 288 264 0.135 0.11 0.225 0.183 Yes
DR180AP135 DR220AP110
VFD1320CP43B-00/43B-21
132 175 220 260 352 312 0.11 0.098 0.183 0.163 Yes
DR220AP110 DR260AP098
VFD1600CP43A-00/43A-21
160 215 260 310 416 372 0.098 0.078 0.163 0.13 Yes
DR260AP098 DR310AP078
VFD1850CP43B-00/43B-21
185 250 310 370 496 444 0.078 0.066 0.13 0.11 Yes
DR310AP078 DR370AP066
VFD2200CP43A-00/43A-21
220 300 370 460 592 552 0.066 0.054 0.11 0.09 Yes
DR370AP066 DR460AP054
VFD2800CP43A-00/43A-21
280 375 460 530 736 636 0.054 0.044 0.09 0.073 Yes
DR460AP054 DR550AP044
VFD3150CP43A-00/43C-00
/ VFD3150CP43A-21
315 420 550 616 880 739.2 0.044 0.039 0.073 0.065 Yes
DR550AP044 DR616AP039
VFD3550CP43A-00/43C-00
/ VFD3550CP43A-21
355 475 616 683 985.6 819.6 0.039 0.036 0.065 0.06 Yes
DR616AP039 DR683AP036
VFD4000CP43A-00/43C-00
/ VFD4000CP43A-21
400 536 683 770 1092.8 924 0.036 0.028 0.06 0.047 Yes
DR683AP036 DR866AP028
VFD5000CP43A-00/43C-00
/ VFD5000CP43A-21
500 930 866 912 1385.6 1094.4 0.028 0.028 0.047 0.043 Yes
DR866AP028
DR866AP028*
2
VFD5600CP43A-00/43C-21
560 650 930 1094 1488 1318.2 0.026 0.022 0.043 0.037 Yes
Please contact Delta for more
information
VFD6300CP43A-00/43C-21
630 750 1094 1212 1750.4 1454.4 0.022 0.020 0.037 0.033 Yes
*Note 1: Use with DR003A0810, but the inductance value will be 3% short.
*Note 2: Use with DR866AP028, the value is 5.3% greater than the rated current, which may cause slightly over-heat.
Table 7-20
