Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-15
575 V, 50 / 60 Hz, 3-phase
Model kW HP
Rated Amps of AC Reactor
(Arms)
Max. continuous
Amps (Arms)
3% Impedance (mH) 5% Impedance (mH)
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
015 1.5 2 2.5 3 4.2 10.567 8.806 17.612 14.677
022 2.2 3 3.6 4.3 5.9 7.338 6.144 12.230 10.239
037 3.7 5 5.5 6.7 9.1 4.803 3.943 8.005 6.572
055 5.5 7.5 8.2 9.9 13.7 3.222 2.668 5.369 4.447
075 7.5 10 10 12.1 16.5 2.642 2.183 4.403 3.639
110 11 15 15.5 18.7 25.7 1.704 1.413 2.841 2.355
150 15 20 20 24.2 33.3 1.321 1.092 2.201 1.819
690V, 50 / 60 Hz, 3-phase
Model kW HP
Rated Amps of AC Reactor
(Arms)
Max. continuous
Amps (Arms)
3% Impedance (mH) 5% Impedance (mH)
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
Normal
Duty
Light
Duty
185
18.5
25 20 24 30.0 28.8 1.902 1.585 3.170 2.642
220
22
30 24 30 36.0 36.0 1.585 1.268 2.642 2.113
300
30
40 30 36 45.0 43.2 1.268 1.057 2.113 1.761
370
37
50 36 45 54.0 54.0 1.057 0.845 1.761 1.409
450
45
60 45 54 67.5 64.8 0.845 0.704 1.409 1.174
550
55
75 54 67 81.0 80.4 0.704 0.568 1.174 0.946
750
75
100 67 86 100.5 103.2 0.568 0.442 0.946 0.737
900
90
125 86 104 129.0 124.8 0.442 0.366 0.737 0.610
1100
110
150 104 125 156.0 150.0 0.366 0.304 0.610 0.507
1320
132
175 125 150 187.5 180.0 0.304 0.254 0.507 0.423
1600
160
215 150 180 225.0 216.0 0.254 0.211 0.423 0.352
2000
200
270 180 220 270.0 264.0 0.211 0.173 0.352 0.288
2500
250
335 220 290 330.0 348.0 0.173 0.131 0.288 0.219
3150
315
425 290 350 435.0 420.0 0.131 0.109 0.219 0.181
4000
400
530 350 430 525.0 516.0 0.109 0.088 0.181 0.147
4500
450
600 385 465 577.5 558.0 0.099 0.082 0.165 0.136
5600
560
745 465 590 697.5 708.0 0.082 0.064 0.136 0.107
6300
630
850 675 675 1012.5 810.0 0.056 0.056 0.094 0.094
Table 7-21
Table 7-22

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
