Delta CP2000 Series User Manual

Chapter 7 Optional AccessoriesCP2000
7-51
460V
Model
kW HP
Rated current
(Arms)
Without AC output reactor 3% With AC output reactor
Normal
Duty
Light
Duty
Shielded Cable
[meter]
Non-shielded cable
[meter]
Shielded Cable
[meter]
Non-shielded cable
[meter]
007 0.75 1 1.7 3 50 75 75 115
015 1.5 2 3 4.2 50 75 75 115
022 2.2 3 4 5.5 50 75 75 115
037 3.7 5 6 8.5 50 75 75 115
040 4 5 9 10.5 50 75 75 115
055 5.5 7.5 10.5 13 50 75 75 115
075 7.5 10 12 18 100 150 150 225
110 11 15 18 24 100 150 150 225
150 15 20 24 32 100 150 150 225
185 18.5 25 32 38 100 150 150 225
220 22 30 38 45 100 150 150 225
300 30 40 45 60 100 150 150 225
370 37 50 60 73 100 150 150 225
450 45 60 73 91 150 225 225 325
550 55 75 91 110 150 225 225 325
750 75 100 110 150 150 225 225 325
900 90 125 150 180 150 225 225 325
1100 110 150 180 220 150 225 225 325
1320 132 175 220 260 150 225 225 325
1600 160 215 260 310 150 225 225 325
1850 185 250 310 370 150 225 225 325
2200 220 300 370 460 150 225 225 325
2800 280 375 460 530 150 225 225 325
3150 315 420 550 616 150 225 225 325
3550 355 475 616 683 150 225 225 325
4000 400 536 683 770 150 225 225 325
5000 500 675 866 912 150 225 225 325
5600 560 650 930 1094 150 225 225 325
6300 630 750 1094 1212 150 225 225 325
575V
Model
kW HP
Rated current
(Arms)
Normal Duty
Without AC output reactor 3% With AC output reactor
Shielded Cable
[meter]
Non-shielded
cable [meter]
Shielded Cable
[meter]
Non-shielded
cable [meter]
VFD022CP53A-21 1.5 2 3.6 35 30 45 20
VFD037CP53A-21 2.2 3 5.5 35 30 45 20
VFD055CP53A-21 3.7 5 8.2 35 30 45 20
VFD075CP53A-21 5.5 7.5 10 35 30 45 20
VFD110CP53A-21 7.5 10 15.5 35 30 45 20
VFD150CP53A-21 11 15 20 35 30 45 20
Table 7-60
Table 7-61

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
