Delta CP2000 Series User Manual

Chapter 09 SpecificationsCP2000
9-6
9-4 690V Series
Frame C D E
Model VFD_ _ _ _CP63A-_ _ 185 220 300 370 450 550 750 900 1100 1320
*Out
p
ut ratin
g
Light duty
Rated output capacity
[kVA]
29 36 43 54 65 80 103 124 149 179
Applicable motor output
690V [kW]
18.5 22 30 37 45 55 75 90 110 132
Applicable motor output
690V [HP]
25 30 40 50 60 75 100 125 150 175
Applicable motor output
575V [HP]
20 25 30 40 50 60 75 100 125 150
Rated output current [A] 24 30 36 45 54 67 86 104 125 150
Overload tolerance 120% of rated current for 1 minute during every 5 minutes
Max.output frequency
[Hz]
599.00
Normal dut
y
Rated output capacity
[kVA]
24 29 36 43 54 65 80 103 124 149
Applicable motor output
690V [kW]
15 18.5 22 30 37 45 55 75 90 110
Applicable motor output
690V [HP]
20 25 30 40 50 60 75 100 125 150
Rated output capacity
575V [HP]
15 20 25 30 40 50 60 75 100 125
Rated output current [A] 20 24 30 36 45 54 67 86 104 125
Overload tolerance
120% of rated current for 1 minute during every 5 minutes;
160% of rated current for 3 seconds during every 25 seconds
Max.output frequency
[Hz]
599.00
Carrier frequency [kHz] 2–9 (Default: 4)
I
n
p
ut ratin
g
Input current
[A]
Light duty 29 36 43 54 65 81 84 102 122 147
Normal duty 24 29 36 43 54 65 66 84 102 122
Rated voltage / Frequency 3-phase, 525–690 V
A
C
(-15%– +10%), 50/60 Hz
Operating voltage range 446–759 V
A
C
Frequency tolerance 47–63 Hz
Efficiency [%] 97
Power factor >0.98
Weight [Kg] 10± 1.5 39± 1.5 61± 1.5
Cooling method Fan cooling
Braking chopper Frame C: Built-in Frame D–E: Optional
DC choke Frame C: Optional Frame D–E: Built-in
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter
9-7 Derating Curve of Ambient Temperature.
 Select the AC motor drive with capacity one grade larger for the impact load application.
 Refer to Chapter 9-6 Specification for Operation Temperature and Protection Level for the protection level of each model.
 * The default setting is Light Duty, you can select Normal Duty and Light Duty by setting Pr.00-16.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
