690V Series
Frame F G H
Model VFD_ _ _ _CP63A-_ _ 1600 2000 2500 3150 4000 4500 5600 6300
*Out
p
ut ratin
g
Li
g
ht dut
y
Rated output capacity
[kVA]
215 263 347 418 494.5 534.7 678.5 776
Applicable motor output
690V [kW]
160 200 250 315 400 450 560 630
Applicable motor output
690V [HP]
215 270 335 425 530 600 745 850
Applicable motor output
575V [HP]
150 200 250 350 400 450 500 675
Rated output current [A] 180 220 290 350 430 465 590 675
Overload tolerance 120% of rated current for 1 minute during every 5 minutes
Max.output frequency
[Hz]
599.00
Normal dut
y
Rated output capacity
[kVA]
179 215 239 347 402.5 442.7 534.7 776
Applicable motor output
690V [kW]
132 160 200 250 315 355 450 630
Applicable motor output
690V [HP]
175 215 270 335 425 475 600 850
Rated output capacity
575V [HP]
150 150 200 250 350 400 450 500
Rated output current [A] 150 180 220 290 350 385 465 675
Overload tolerance
120% of rated current for 1 minute during every 5 minutes;
160% of rated current for 3 seconds during every 25 seconds
Max.output frequency
[Hz]
599.00
Carrier frequency [kHz] 2–9 (Default: 4)
2–9
(Default: 3)
Input
rating
Input current [A] Light duty 178 217 292 353 454 469 595 681
Input current [A] Normal duty 148 178 222 292 353 388 504 681
Rated voltage / Frequency 3-phase, 525–690 V
A
C
(-15%– +10%), 50/60 Hz
Operating voltage range 446–759 V
A
C
Frequency tolerance 47–63 Hz
Efficiency [%] 97 98
Power factor >0.98
Weight [Kg] 88± 1.5 135± 4 243± 5
Cooling method Fan cooling
Braking chopper Frame F–H: Optional
DC choke Frame F–H: Built-in
NOTE
 The carrier frequency is default. Increasing the carrier frequency requires a reduction in current. Please refer to Chapter
9-7 Derating Curve of Ambient Temperature.
 Select the AC motor drive with capacity one grade larger for the impact load application.
 Refer to Chapter 9-6 Specification for Operation Temperature and Protection Level for the protection level of each model.
 * The default setting is Light Duty, you can select Normal Duty and Light Duty by setting Pr.00-16.

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
