Delta CP2000 Series User Manual

Chapter 11 Summary of Parameter SettingsCP2000
11-32
09 Communication Parameters
Pr. Parameter Name Setting Range Default
 09-00 COM1 communication address 1–254 1
 09-01 COM1 transmission speed 4.8–115.2 Kbps 9.6
 09-02 COM1 transmission fault treatment
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: No warning and continue operation
3
 09-03 COM1 time-out detection 0.0–100.0 sec. 0.0
 09-04 COM1 communication protocol
1: 7, N, 2 (ASCII)
2: 7, E, 1 (ASCII)
3: 7, O, 1 (ASCII)
4: 7, E, 2 (ASCII)
5: 7, O, 2 (ASCII)
6: 8, N, 1 (ASCII)
7: 8, N, 2 (ASCII)
8: 8, E, 1 (ASCII)
9: 8, O, 1 (ASCII)
10: 8, E, 2 (ASCII)
11: 8, O, 2 (ASCII)
12: 8, N, 1 (RTU)
13: 8, N, 2 (RTU)
14: 8, E, 1 (RTU)
15: 8, O, 1 (RTU)
16: 8, E, 2 (RTU)
17: 8, O, 2 (RTU)
1
 09-09 Communication response delay time 0.0–200.0 ms 2.0
09-10 Communication main frequency 0.00–599.00 Hz 60.00
 09-11 Block transfer 1 0000–FFFFh 0000h
 09-12 Block transfer 2 0000–FFFFh 0000h
 09-13 Block transfer 3 0000–FFFFh 0000h
 09-14 Block transfer 4 0000–FFFFh 0000h
 09-15 Block transfer 5 0000–FFFFh 0000h
 09-16 Block transfer 6 0000–FFFFh 0000h
 09-17 Block transfer 7 0000–FFFFh 0000h
 09-18 Block transfer 8 0000–FFFFh 0000h
 09-19 Block transfer 9 0000–FFFFh 0000h
 09-20 Block transfer 10 0000–FFFFh 0000h
 09-21 Block transfer 11 0000–FFFFh 0000h
 09-22 Block transfer 12 0000–FFFFh 0000h
 09-23 Block transfer 13 0000–FFFFh 0000h
 09-24 Block transfer 14 0000–FFFFh 0000h
 09-25 Block transfer 15 0000–FFFFh 0000h
 09-26 Block transfer 16 0000–FFFFh 0000h
09-30 Communication decoding method
0: Decoding method 1 (20xx)
1: Decoding method 2 (60xx)
1

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
