Chapter 11 Summary of Parameter SettingsCP2000
11-34
Pr. Parameter Name Setting Range Default
4: Enable Operation
7: Quick Stop Active
13: Error Reaction Active
14: Error
09-45 CANopen master function
0: Disable
1: Enable
0
09-46 CANopen master address 0–127 100
09-50 BACnet MS / TP node address 0–127 10
09-51 BACnet baud rate 9.6–76.8 Kbps 38.4
09-52 BACnet Device index L 0–65535 10
09-53 BACnet Device index H 0–63 0
09-55 BACnet Max Address 0–127 127
09-56 BACnet password 0–65535 0
09-60 Communication card identifications
0: No communication card
1: DeviceNet slave
2: Profibus-DP slave
3: CANopen slave / master
4: Modbus –TCP Slave
5: EtherNet/IP Slave
6: EtherCAT
8: BACnet IP
12: PROFINET
Read
Only
09-61 Firmware version of communication card Read only
Read
Only
09-62 Product code Read only
Read
Only
09-63 Fault code Read only
Read
Only
09-70
Communication card address
(for DeviceNet or PROFIBUS)
DeviceNet: 0–63
Profibus-DP: 1–125
1
09-71
Communication card speed setting
(for DeviceNet)
Standard DeviceNet:
0: 100 Kbps
1: 125 Kbps
2: 250 Kbps
3: 1 Mbps (Delta only)
Non-standard DeviceNet: (Delta only)
0: 10 Kbps
1: 20 Kbps
2: 50 Kbps
3: 100 Kbps
4: 125 Kbps
5: 250 Kbps
6: 500 Kbps
7: 800 Kbps
8: 1 Mbps
2
09-72
Additional settings for communication
card speed (for DeviceNet)
0: Standard DeviceNet
In this mode, baud rate can only be 100
Kbps, 125 Kbps, 250 Kbps in standard
0
