Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-09-17
4: 125 Kbps
5: 250 Kbps
6: 500 Kbps
7: 800 Kbps
8: 1 Mbps

Other Communication Card Speed Setting (for DeviceNet)
Default: 0
Settings 0: Standard DeviceNet
In this mode, the baud rate can only be 125 Kbps, 250 Kbps, and 500 Kbps
in standard DeviceNet speed.
1: Nonstandard DeviceNet
In this mode, the baud rate of DeviceNet can be the same as that for
CANopen (0–8).
 Use with Pr.09-71.
 Setting 0: The baud rate can only be set to 125 Kbps, 250 Kbps and 500 Kbps.
 Setting 1: The DeviceNet communication rate can be the same as that for CANopen (setting
0–8).

Communication Card IP Configuration (for Modbus TCP)
Default: 0
Settings 0: Static IP
1: DynamicIP (DHCP)
 Setting 0: Set the IP address manually.
 Setting 1: IP address is automatically set by the host controller.

Communication Card IP Address 1 (for Modbus TCP)

Communication Card IP Address 2 (for Modbus TCP)

Communication Card IP Address 3 (for Modbus TCP)

Communication Card IP Address 4 (for Modbus TCP)
Default: 0
Settings 0–65535
 Use Pr.09-76–09-79 with a communication card.

Communication Card Address Mask 1 (for Modbus TCP)

Communication Card Address Mask 2 (for Modbus TCP)

Communication Card Address Mask 3 (for Modbus TCP)

Communication Card Address Mask 4 (for Modbus TCP)
Default: 0
Settings 0–65535

Communication Card Gateway Address 1 (for Modbus TCP)

Communication Card Gateway Address 2 (for Modbus TCP)

Communication Card Gateway Address 3 (for Modbus TCP)

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
