Delta CP2000 Series User Manual

Chapter 12 Description of Parameter SettingsCP2000
12.1-13-2
Pr. Explanation Settings
05-03 Rated speed for induction motor 1 (rpm) Default setting
05-04 Number of poles for induction motor 1 Default setting
 Group setting 03: Fan
The following table lists the relevant fan setting application parameters.
Pr. Explanation Settings
00-11 Speed control mode 0 (V/F control)
00-16 Load selection 0: Light load
00-17 Carrier frequency Default setting
00-20
Master frequency command source (AUTO)
/ Source selection of the PID target
2: External analog input
00-21 Operation command source (AUTO) 1: External terminals.
00-22 Stop method 1: Coast to stop
00-23 Control of Motor Direction 1: Disable reverse
00-30 Master frequency command (HAND) source 0: Digital keypad
00-31 Operation command (HAND) source 0: Digital keypad
01-00 Maximum operation frequency Default setting
01-01 Output frequency of motor 1 Default setting
01-02 Output voltage of motor 1 Default setting
01-03 Mid-point frequency 1 of motor 1 Default setting
01-04 Mid-point voltage 1 of motor 1 Default setting
01-05 Mid-point frequency 2 of motor 1 Default setting
01-06 Mid-point voltage 2 of motor 1 Default setting
01-07 Minimum output frequency of motor 1 Default setting
01-08 Minimum output voltage of motor 1 Default setting
01-10 Output frequency upper limit 50 (Hz)
01-11 Output frequency lower limit 35 (Hz
01-12 Acceleration time 1 15 (s)
01-13 Deceleration time 1 15 (s)
01-43 V/F curve selection 2: 2
nd
V/F curve
02-05 Multi-function input command 5 (MI5) 16: Rotating speed command from ACI
03-00 Analog input selection (AVI1) 1: Frequency command
03-01 Analog input selection (ACI) 1: Frequency command
03-28 AVI1 terminal input selection 0 (0–10 V)
03-29 ACI terminal input selection 1 (0–10 V)
03-31 AFM output selection 0 (0–10 V)
03-50 Analog input curve selection 1: three-point curve of AVI1
07-06 Restart after momentary power loss
2: Speed tracking by minimum output
frequency
07-11 Number of times of restart after fault 5 (times)
07-33 Auto-restart interval of fault 60 (s)

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
