Delta CP2000 Series User Manual

Chapter 16 PLC Function Applications│CP2000
16-36
Special
D
Description of Function R/W *
D1181 Internal node 6 mode RW
D1182 Internal node 6 reference command L RW
D1183 Internal node 6 reference command H RW
D1184 -- --
D1185 -- --
D1186 Internal node 6 status RO
D1187 Internal node 6 reference status L RO
D1188 Internal node 6 reference status H RO
D1189 -- --
D1190 Internal node 7 control command RW
D1191 Internal node 7 mode RW
D1192 Internal node 7 reference command L RW
D1193 Internal node 7 reference command H RW
D1194 -- --
D1195 -- --
D1196 Internal node 7 status RO
D1197 Internal node 7 reference status L RO
D1198 Internal node 7 reference status H RO
D1199 -- --
Special
D
Description of Function Default R/W*
D1200
PID1 mode:
0: Basic mode
0 RW
D1201
PID1 target selection:
0: Refer to D1202
1: AVI1
2: ACI
3: AVI2
0 RW
D1202 PID1 target value (0.00%–100.00%) 5000 RW
D1203
PID1 feedback selection
0: Refer to D1204
1: AVI1
2: ACI
3: AVI2
1 RW
D1204 PID1 feedback value (0.00%–100.00%) 0 RW
D1205
PID1 P value (decimal point 2)
10 RW
D1206 PID1 I value (decimal point 2) 1000 RW
D1207 PID1 D value (decimal point 2) 0 RW
D1209 Max. limit of PID1 10000 RW
D1215 Counting value of PID1 (decimal point 2) 0 RO
D1220
PID2 mode:
0: Basic mode
0 RW
D1221
PID2 target selection:
0: Refer to D1202
1: AVI1
2: ACI
3: AVI2
0 RW
D1222 PID2 target value (0.00%–100.00%) 5000 RW
D1223
PID2 feedback selection
0: Refer to D1204
1: AVI1
2: ACI
3: AVI2
1 RW
D1224 PID2 feedback value (0.00%–100.00%) 0 RW

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
