Delta CP2000 Series User Manual

Chapter 17 Introduction to BACnet │CP2000
17-10
Data Link Layer Options:
 BACnet IP, (Annex J)
 BACnet IP, (Annex J), Foreign Device
 ISO 8802-3, Ethernet (Clause 7)
 ANSI/ATA 878.1, 2.5 Mb. ARCNET (Clause 8)
 ANSI/ATA 878.1, RS-485 ARCNET (Clause 8), baud rate(s) ____________
 MS/TP master (Clause 9), baud rate(s): 9600, 19200, 38400, 76800
 MS/TP slave (Clause 9), baud rate(s): ________
 Point-To-Point, EIA 232 (Clause 10), baud rate(s):
 Point-To-Point, modem, (Clause 10), baud rate(s):
 LonTalk, (Clause 11), medium: __________
 Other:
Device Address Binding:
Is static device binding supported? (This is currently necessary for two-way communication with MS/TP slaves and
certain other devices.) Yes No
Networking Options:
 Router, Clause 6 - List all routing configurations, e.g., ARCNET-Ethernet, Ethernet-MS/TP, etc.
 Annex H, BACnet Tunneling Router over IP
 BACnet/IP Broadcast Management Device (BBMD)
Does the BBMD support registrations by Foreign Devices?  Yes  No
Character Sets Supported:
Indicating support for multiple character sets does not imply that they can all be supported simultaneously.
 ANSI X3.4  IBM

/Microsoft

DBCS  ISO 8859-1
 ISO 10646 (UCS-2)  ISO 10646 (UCS-4)  JIS C 6226
If this product is a communication gateway, describe the types of non-BACnet equipment/networks(s) that
the gateway supports:
___________________________________________________________________________________________
____
___________________________________________________________________________________________
____

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
