Chapter 17 Introduction to BACnet │CP2000
17-14
Object
Number
R/W Object Name Object Description Unit
AV 059 R AV_059_KW per Hour KW per Hour UNITS_KILOWATTS
AV 060 R AV_060_Multi-speed switch Real multi-speed switch UNITS_NO_UNITS
AV 061 R AV_061_AVI1 input value 0~10V corresponds to 0~100% UNITS_PERCENT
AV 062 R AV_062_ACI input value 4~20mA/0~10V corresponds to 0~100% UNITS_PERCENT
AV 063 R AV_063_AVI2 input value 0V~10V corresponds to 0~100% UNITS_PERCENT
AV 064 R AV_064_Digital input status Refer to P2-12 UNITS_NO_UNITS
AV 065 R AV_065_Digital output status Refer to P2-18 UNITS_NO_UNITS
AV 066 R AV_066_CPU pin status of DI Corresponding CPU pin status of digital input UNITS_NO_UNITS
AV 067 R AV_067_CPU pin status of DO Corresponding CPU pin status of digital output UNITS_NO_UNITS
AV 068 R AV_068_PLC D1043 value PLC D1043 value UNITS_NO_UNITS
Commandable Binary Value Object
In VFD-CP2000, we have BV_000–BV_015 supporting commandable Present_Value property. In
these BV_Objects, we also can use (Multi) Read_Service to access Priority_Array and
Relinquish_Default properties.
Object
Number
R/W Object Name Object Description
BV 000 RW BV_000_ACTIVE CMD (0)FreqCmd=0;(1)FreqCmd=FreqRefValue
BV 001 RW BV_001_FWD/REV CMD (0)Forward; (1)Reverse
BV 002 RW BV_002_Reserved Reserved
BV 003 RW BV_003_HALT CMD (0)None;(1)RampDown to 0Hz.
BV 004 RW BV_004_LOCK CMD (0)None;(1)OutputFreq stays at current frequency
BV 005 RW BV_005_Reserved Reserved
BV 006 RW BV_006_QSTOP CMD (0)None;(1)Force driver quick stop
BV 007 RW BV_007_ServoPower CMD (0)PowerOff(free run to stop);(1)PowerOn
BV 008 RW BV_008_Reserved Reserved
BV 009 RW BV_009_Reserved Reserved
BV 010 RW BV_010_Reserved Reserved
BV 011 RW BV_011_Reserved Reserved
BV 012 RW BV_012_Reserved Reserved
BV 013 RW BV_013_Reserved Reserved
BV 014 RW BV_014_Reserved Reserved
BV 015 RW BV_015_RESET RESET:(0)Do nothing;(1)Reset fault
