Delta CP2000 Series User Manual

Chapter 5 Main Circuit TerminalsCP2000
5-9
Frame A
-/D
C
- +
2
/D
C
++1/D
C
+B1 B
2
R/L1 S/L2 T/L3 U/T1 V/T2 W/T3
 If you install at Ta 50°C environment, please select copper wire with voltage rating 600V and
temperature resistant at 75°C or 90°C.
 If you install at Ta 50°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.
 For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the
wire gauge when using higher temperature wire.
Model Name
Main Circuit Terminals
R/L1, S/L2, T/L3, U/T1, V/T2, W/T3, B1,
B2, -/DC-, +2/DC+, +1/DC+
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
VFD007CP23A-21
10 mm
2
[8 AWG]
2.5 mm
2
[14 AWG]
M4
20kg-cm
[17.4lb-in.]
[1.96Nm]
2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
M4
20kg-cm
[17.4lb-in.]
[1.96Nm]
VFD015CP23A-21 4.0 mm
2
[12 AWG] 4.0 mm
2
[12 AWG] 4.0 mm
2
[12 AWG]
VFD022CP23A-21 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG]
VFD037CP23A-21 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG]
VFD055CP23A-21 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG]
VFD007CP43A-21 1.5 mm
2
[16 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD015CP43B-21 1.5 mm
2
[16 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD022CP43B-21 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD037CP43B-21 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG]
VFD040CP43A-21 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG]
VFD055CP43B-21 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG]
VFD075CP43B-21 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG]
VFD007CP4EA-21 1.5 mm
2
[16 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD015CP4EB-21 1.5 mm
2
[16 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD022CP4EB-21 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD037CP4EB-21 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG]
VFD040CP4EA-21 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG] 6.0 mm
2
[10 AWG]
VFD055CP4EB-21 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG]
VFD075CP4EB-21 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG] 10.0 mm
2
[8 AWG]
VFD015CP53A-21 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD022CP53A-21 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]
VFD037CP53A-21 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG] 2.5 mm
2
[14 AWG]

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
