Delta CP2000 Series User Manual

Chapter 5 Main Circuit TerminalsCP2000
5-16
Frame G
R
/L
1
1
S
/L
2
1
T/L
3
1
U
/T
1
V/T
2
W/T
3
-/D
C
- +
1
/D
C
+
R
/L
1
2
S
/L
2
2
T/L
3
2
 If you install at Ta 40°C environment, please select copper wire with voltage rating 600V and
temperature resistant at 75°C or 90°C.
 If you install at Ta 40°C above environment, please select copper wire with voltage rating 600V and
temperature resistant at 90°C or above.
 For UL installation compliant, please use copper wires for installation, the wire gauge is based on
temperature resistant at 75°C which is requested and recommended from UL. Do not reduce the wire
gauge when using higher temperature wire.
Model Name
Main Circuit Terminals
R/L11, R/L12, S/L21, S/L22, T/L31, T/L32
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
VFD2200CP43A-00
120mm
2
*4
[250MCM*4]
95mm
2
*4 [3/0AWG*4]
M8
180kg-cm
[156.2lb-in.]
[17.65Nm]
95mm
2
*4 [3/0AWG*4] 95mm
2
*2 [3/0AWG*2]
M8
180kg-cm
[156.2lb-in.]
[17.65Nm]
VFD2800CP43A-00 120mm
2
*4 [4/0AWG*4] 120mm
2
*4 [4/0AWG*4] 120mm
2
*2 [4/0AWG*2]
VFD2200CP43A-21 70mm
2
*4 [2/0AWG*4] 70mm
2
*4 [2/0AWG*4] 70mm
2
*2 [2/0AWG*2]
VFD2800CP43A-21 95mm
2
*4 [3/0AWG*4] 95mm
2
*4 [3/0AWG*4] 95mm
2
*2 [3/0AWG*2]
VFD2500CP63A-00
150mm
2
*4
[300MCM*4]
50mm
2
*4 [1/0AWG*4] 50mm
2
*4 [1/0AWG*4] 50mm
2
*2 [1/0AWG*2]
VFD3150CP63A-00 50mm
2
*4 [1/0AWG*4] 50mm
2
*4 [1/0AWG*4] 50mm
2
*2 [1/0AWG*2]
VFD2500CP63A-21 50mm
2
*4 [1/0AWG*4] 50mm
2
*4 [1/0AWG*4] 50mm
2
*2 [1/0AWG*2]
VFD3150CP63A-21 50mm
2
*4 [1/0AWG*4] 50mm
2
*4 [1/0AWG*4] 50mm
2
*2 [1/0AWG*2]
Model Name
Main Circuit Terminals
U/T1, V/T2, W/T3, +1/DC+, -/DC-
Terminal
Max. Wire
Gauge
Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
Max. Wire Gauge Min. Wire Gauge
Screw
Spec. and
Torque
(±10%)
VFD2200CP43A-00
240mm
2
*2
[500MCM*2]
240mm
2
*2 [400MCM*2]
M12
408kg-cm
[354.1lb-in.]
[39.98Nm]
240mm
2
*2
[400MCM*2]
240mm
2
*1 [400MCM*1]
M8
180kg-cm
[156.2lb-in.]
[17.65Nm]
VFD2800CP43A-00 240mm
2
*2 [500MCM*2]
240mm
2
*2
[500MCM*2]
240mm
2
*1 [500MCM*1]
VFD2200CP43A-21 240mm
2
*2 [400MCM*2]
240mm
2
*2
[400MCM*2]
240mm
2
*1 [400MCM*1]
VFD2800CP43A-21 240mm
2
*2 [500MCM*2]
240mm
2
*2
[500MCM*2]
240mm
2
*1 [500MCM*1]
VFD2500CP63A-00 120mm
2
*2 [250MCM*2]
120mm
2
*2
[250MCM*2]
120mm
2
*1 [250MCM*1]
VFD3150CP63A-00 150mm
2
*2 [350MCM*2]
150mm
2
*2
[350MCM*2]
150mm
2
*1 [350MCM*1]
VFD2500CP63A-21 120mm
2
*2 [250MCM*2]
120mm
2
*2
[250MCM*2]
120mm
2
*1 [250MCM*1]
VFD3150CP63A-21 150mm
2
*2 [350MCM*2]
150mm
2
*2
[350MCM*2]
150mm
2
*1 [350MCM*1]

Delta CP2000 Series Specifications

General

Output Voltage	0 ~ Input Voltage
Communication Interface	RS-485
Storage Temperature	-20°C to 60°C
Input Voltage	200-240V AC, 380-480V AC
Protection Functions	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
